Forklift Brakes
Forklift Brakes - A brake drum is where the friction is provided by the brake pads or brake shoes. The shoes or pads press up against the rotating brake drum. There are a few various brake drums kinds along with certain specific differences. A "break drum" would generally refer to if either pads or shoes press onto the interior surface of the drum. A "clasp brake" is the term used to describe if shoes press against the exterior of the drum. One more type of brake, known as a "band brake" utilizes a flexible belt or band to wrap around the outside of the drum. If the drum is pinched in between two shoes, it could be referred to as a "pinch brake drum." Like a typical disc brake, these kinds of brakes are somewhat rare.
Old brake drums, previous to the year 1995, required to be constantly modified to be able to compensate for wear of the shoe and drum. "Low pedal" can cause the needed adjustments are not carried out satisfactorily. The vehicle could become hazardous and the brakes could become useless if low pedal is mixed together with brake fade.
There are different Self Adjusting Brake Systems offered, and they can be categorized within two main types, RAD and RAI. RAI systems have built in equipments which avoid the systems to recover when the brake is overheating. The most well known RAI makers are AP, Bendix, Lucas, and Bosch. The most famous RAD systems include AP, Bendix, Ford recovery systems and Volkswagen, VAG.
Self repositioning brakes generally utilize a tool that engages only when the motor vehicle is being stopped from reverse motion. This stopping method is suitable for use where all wheels utilize brake drums. The majority of vehicles now use disc brakes on the front wheels. By working only in reverse it is less possible that the brakes would be adjusted while hot and the brake drums are expanded. If adjusted while hot, "dragging brakes" could happen, which raises fuel intake and accelerates wear. A ratchet mechanism that becomes engaged as the hand brake is set is one more way the self repositioning brakes can work. This means is just suitable in applications where rear brake drums are used. Whenever the emergency or parking brake actuator lever goes over a specific amount of travel, the ratchet advances an adjuster screw and the brake shoes move in the direction of the drum.
Located at the bottom of the drum sits the manual adjustment knob. It can be tweaked using the hole on the other side of the wheel. You will have to go beneath the vehicle using a flathead screwdriver. It is very important to be able to adjust every wheel equally and to be able to move the click wheel correctly since an unequal adjustment can pull the vehicle one side during heavy braking. The most efficient method so as to make certain this tiresome job is done safely is to either lift every wheel off the ground and hand spin it while measuring how much force it takes and feeling if the shoes are dragging, or give each one the same amount of clicks utilizing the hand and then do a road test.
